Nickel 200/201 (899L) – UNS N02200, N02201 – WNR 2.4068
Nickel 201/200 strip (899L) is our premier battery grade that offers improved conductivity over Nickel 200 and Nickel 201 strip while maintaining closer mechanical properties to the lower conductivity materials.
Nickel 200/201 (899M) – UNS N02200, N02201 – WNR 2.4068
Nickel 201/200 (899M) is produced as a replacement for Nickel 200 material and Nickel 201 strip with similar mechanical properties and without the higher conductivities attributed to higher purity grades such as 899L and 899A.
We offer these two high purity, roll compacted Nickel Strip grades as a replacement for Nickel 200 and Nickel 201 strip. Our roll compacted material provides higher purity than standard wrought and cast Nickel Strip. The higher purity reduces impedance, increases conductivity, and therefore improves performance.
Applications
Battery connectors and tabs used to combine multiple individual batteries into a pack.
Chemical Composition
All values are maximum weight percent unless indicated as typical.
| Element |
Alloy 899L |
Alloy 899M |
UNS Equivalent
Alloy N02201 / N02200 |
| C |
0.02 |
0.02 |
|
| Co |
0.01 |
0.01 |
|
| Cr |
0.005 |
0.005 |
|
| Si |
0.005 |
0.005 |
|
| Mn |
0.05 typical |
0.02 typical |
|
| S |
0.001 |
0.001 |
|
| Cn |
0.005 |
0.005 |
|
| Fe |
0.05 |
0.05 |
|
| Mg |
0.002 |
0.002 |
|
| Sn |
0.005 |
0.005 |
|
| Ni |
99.8 |
99.6 |
|
| Al |
0.005 |
0.005 |
|
| Ti |
0.005 |
0.005 |
|
Electrical Resistivity
At 70°F for Alloy 899 Nickel OHM/CMF.
| Nickel Grade |
Annealed |
50% Cold Work |
| Alloy 899L |
45.1 (a) |
45.6 |
| Alloy 899M |
46.7 |
47.6 |
| Comparative Data for Wrought and Cast Nickel |
| Nickel 201 UNS N02201 |
59.6 |
62.2 |
| Nickel 201 UNS N02201 |
52.0 (b) |
|
| Nickel 200 UNS N02200 |
57.0 |
59.2 |
(a) Special grade with 44 maximum value available
(b) Handbook value
Mechanical Property Comparisons
899 Nickel Properties in the 50% Cold Rolled and Annealed (30 min. at 1450°F) Condition.
| Annealed Properties |
| Grade |
Tensile Strength ksi |
Yield Strength ksi |
Elongation % In 2 Inches |
Vicker Hardness |
| Alloy 899L |
53.5 |
15.5 |
44 |
73 |
| Alloy 899M |
57.5 |
16.5 |
43 |
78 |
| Comparative Data for Wrought and Cast Alloys |
| Nickel 201 UNS N02201 |
57.7 |
17.3 |
42 |
95 |
| 50% Cold Rolled Properties |
| Grade |
Tensile Strength ksi |
Yield Strength ksi |
Elongation % In 2 Inches |
Vicker Hardness |
| Alloy 899L |
97.0 |
94.0 |
2-8 |
208 |
| Alloy 899M |
98.5 |
95.5 |
2-5 |
210 |
| Comparative Data for Wrought and Cast Alloys |
| Nickel 201 UNS N02201 |
98.5 |
96.5 |
1-4 |
209 |
Range of Typical Mechanical Properties
For Alloy 899L and Alloy 899M.
| Temper |
UTS |
0.2% YS |
Elongation |
Rockwell B |
Vickers Hardness |
| Annealed |
50-58 |
15-20 |
40-45 |
46 max. |
64-90 |
| Skin Hard |
52-65 |
20-45 |
30-40 |
64-70. |
110--126 |
| ¼ Hard |
55-70 |
25-55 |
20-35 |
70-80 |
120-151 |
| ½ Hard |
60-80 |
50-75 |
15-25 |
79-86 |
148-171 |
| ¾ Hard |
70-90 |
65-85 |
5-10 |
85-91 |
168-193 |
| Hard |
85 -100 |
80-95 |
3-6 |
91 min. |
193-203 |
| Full Hard |
94 -103 |
90-100 |
12 |
93 min. |
>203 |
Softening Temperature
| Grade |
| Softening Point for 50% Cold Rolled Temper |
| Softening Curve1 Knee, Temperature °F |
Half Hard Softening2 Temperature °F |
| Alloy 899L |
750 |
800 |
| Alloy 899M |
870 |
910 |
1) Approximate temperature at which rapid softening occurs. Refer to included softening curves.
2) Defined as that temperature at which one half of the hardness imparted by cold rolling is lost during 30 minutes time at temperature softening test.
Applicable Specifications
899 Nickel Strip meets: ASTM B-162, ASTM F-3, ASTM F-239, MIL-N-19153 and MIL-N-46025
The data herein are subject to revision without notice. Since AMETEK products, and the information given and recommendations made herein, may be used under conditions beyond our control, AMETEK makes no guarantee, either expressed or implied, concerning the sustainability of our products, or the applicability and accuracy of the information, or recommendations, in any specific situation. User is solely responsible for determining the suitability of AMETEK products of any specific purpose.
